Ventech Clip-In Retrofit Grille - VCR250

250 mm

For bathrooms, showers, laundries & kitchens.

Regular price: $334.00 NZD
Regular price
Sale price: $334.00 NZD
Unit price: per

GST inclusive

Dimensions 250x250

Product variants

Quantity

Easy-Fit One-Piece Framed Extract Grille for Retrofit Applications

The Ventech VCR250 is a single-piece framed extract grille designed for fast, clean retrofit installations where a designed finish is required. Suitable for plasterboard ceilings and walls of varying thicknesses, the grille features a clip-in attachment system—eliminating the need for battens, screws, plastering, or painting.

Engineered for effective airflow, the VCR250 is fitted with a 150mm spigot to ensure optimal extract performance.

Full Dimensions

Dimensions: 255mm x 255mm
Plaque size: 200 x 200mm
Top spigot: 150mm dia

Specifications

- Ventech VCR250 framed grille with clip in attachment.
- 150mm spigot.
- If required, the exposed surfaces can be re-coloured by painting at the same
time as the ceiling.
- Suitable fans, ductwork and exterior grilles also available.
- At a typical flow rate of 60-70 litres per second, pressure drop is 26 pa.
